CHARACTERSTIC AND PARAMETERS

  • Horizontal installation of washing room and washing dewatering bucket, anti-corrosion; The inner liner is made of high-quality stainless steel material welded together. Key components are sourced from imported or domestic high-quality brands.
  • Adopting a fully suspended shock-absorbing structure and variable frequency drive, the acceleration is smooth and effectively resolves the vibration of the machine. During dehydration, the amplitude is small, the dehydration force is large, and the moisture content of the clothes after dehydration is better than the national standard, without the need for a foundation.
  • The frequency converter adopts an Easy Energy frequency converter, which can set the speed arbitrarily according to actual needs.
  • Easy to operate, fully automatic computer control system, Chinese large screen LCD display, clear washing process at a glance, and free selection of washing program.
  • Steam heating and electric heating can be used as options, and rear drainage can be used, which can be led to the trench with a hose to maintain indoor cleanliness.
  • The feeding box uses hot water flushing to solve the problems of laundry detergent being difficult to dissolve in cold water and prone to scaling.
  • Dehydration safety control function.
  • High and low water level automatic control system, fully computer-controlled program, with 4 manual water level settings to choose from, and automatic water temperature control to choose from.
  • The safety door lock and control linkage device have protective functions (can refuse misoperation such as opening the door when the equipment is running).
  • The body and base are welded together, and all internal and external structures of the machine are coated with epoxy resin paint with strong corrosion resistance. The external panels of the body are made of stainless steel plates.
Model XGQ-16N Motor power (KW) 2.2
Rated capacity (Kg) 16~17 Inverter (KW) 2.2
Transfer cage volume (Lt) 163 Drainage valve (mm) Φ50
Cage size (mm) Φ730×390 Hot water pipe (mm) DN20
Washing speed (r/min) 40 Cold water pipe (mm) DN20
Uniformly distributed speed (r/min) 72 Steam pipe DN15
Clothing door diameter (mm) 420 Dimensions (mm) Height 1550
Mid cycle (r/min) 400 Depth 980
High viscosity (r/min) 860 Width 980
Electric heating power (KW) 7.5 Whole machine weight (Kg) 630
Model XGQ-22N Motor power (KW) 3
Rated capacity (Kg) 22~23 Inverter (KW) 3.7
Transfer cage volume (Lt) 226 Drainage valve (mm) Φ50
Cage size (mm) Φ730×540 Hot water pipe (mm) DN20
Washing speed (r/min) 37 Cold water pipe (mm) DN20
Uniformly distributed speed (r/min) 72 Steam pipe DN20
Clothing door diameter (mm) 420 Dimensions (mm) Height 1550
Mid cycle (r/min) 400 Depth 1150
High viscosity (r/min) 900 Width 980
Electric heating power (KW) 7.5 Whole machine weight (Kg) 700
Model XGQ-25N Motor power (KW) 3
Rated capacity (Kg) 25 Inverter (KW) 3.7
Transfer cage volume (Lt) 250 Drainage valve (mm) Φ50
Cage size (mm) Φ700×650 Hot water pipe (mm) DN20
Washing speed (r/min) 37 Cold water pipe (mm) DN20
Uniformly distributed speed (r/min) 72 Steam pipe DN20
Clothing door diameter (mm) 420 Dimensions (mm) Height 1610
Mid cycle (r/min) 400 Depth 1250
High viscosity (r/min) 800 Width 1110
Electric heating power (KW) 7.5 Whole machine weight (Kg) 750
