CHARACTERSTIC AND PARAMETERS
- This machine adopts variable frequency speed regulation, and users can choose the appropriate ironing speed according to the needs and ironing conditions of different fabrics.
- The method of heating the surface of the drum by burning gas through the drying cylinder has a high thermal efficiency.
- This machine adopts a reducer for deceleration, with a large speed ratio, strong overload capacity, and low voice.
- Adopting chain transmission, it has a large load-bearing capacity.
- The conveying system adopts a wide belt to avoid the difficult problem of wide canvas movement during transmission.
- There is a certain speed difference between the rollers, resulting in better flattening effect.
- The gas inlet of the dryer is equipped with a pressure reducing valve, electronic switch, and fire control knob, which is convenient and reliable.
- Our company has successfully developed four and five rolling ironing machines, and users can upgrade and transform the ironing machines according to specific situations.
| Model | YPI-8030R | YPI-8033R | YPII-8030R | YPII-8033R |
|---|---|---|---|---|
| Motor power (kW) | 1.5 | 1.5 | 2.2 | 2.2 |
| Gas consumption (steam heating type) (kg/h) | 3~3.6 | 3~3.6 | 6~7.2 | 6~7.2 |
| Gas pressure (steam heating type) (KPa) | 2000~2500 | 2000~2500 | 2000~2500 | 2000~2500 |
| Rated voltage (V) | 220V/380V | 220V/380V | 220V/380V | 220V/380V |
| Flattening speed (m/min) | 0~6 | 0~6 | 0~10 | 0~10 |
| Machine weight approximately (t) | 1.2 | 1.2 | 2.4 | 2.4 |
| External dimensions (length × width × height) mm | 4200×1400×1400 | 4500×1400×1400 | 4200×2600×1400 | 4500×2600×1400 |
